Capsule Pressure Gauge Mbar Meter Back Mount 100 cmH2O
Capsule Pressure Gauge Mbar Meter Back Mount 100 cmH2O
This 100 cmH2O Capsule Pressure Gauge Mbar Meter Back Mount is an essential tool to accurately measure and monitor pressure levels. It features a quality 100 cmH2O bellows pressure gauge with a mbar meter for precise and reliable readings. It is back mountable, making it an ideal choice for a wide range of applications.
The 100 cmH2O Capsule Pressure Gauge Meter is designed for low pressure measurement and features a screw-in lens for precise readings. This robust pressure gauge provides a reliable way to monitor and measure levels up to 100 cmH2O.
| Dial Size | 63mm |
| Case material | Stainless steel |
| Wetted parts | Brass |
| Mount | Axial |
| Connection | 1/4 PT, NPT, G... M14*1.5 |
|
Custom options (pressure gauge mbar |
Pressure range |
This 100 cmH2O Capsule Pressure Gauge Mbar Meter Back Mount offers superior accuracy and performance, with bellows manometer and mbar meter readings for precise measurement. Its back mount design enables easy installation and maintenance.
Applications
Low pressure gauge for applications in a controlled environment
Low pressure pneumatic systems
Ideal for measuring pressure, vacuum in medical, environmental, and laboratory applications for content and filter monitoring
For gaseous, dry and non-aggresive media
-
Special features
Front zero adjustment
Special connections on request
Scale ranges from 0/10 InWC (25 mbar)
-
Payment & Shipping Terms
MOQ: 100 Pieces
Price: To be confirmed
Delivery Time: 3~5 weeks
Payment Term: T/T
